EVAL-ADUCM420QSP1Z
User Guide
UG-1926

EVAL-ADUCM420QSP1Z PHOTOGRAPH

POWER TERMINAL
BLOCK
9V WALL WART
AINx
Digital I/Os
VDACx
UART CONNECTOR
J-LINK CONNECTOR
UART/USB
mIDAS-Link
Figure 1.
Rev. 0 | Page 3 of 20
