Sioux Tools 2 1/2 Series Instructions

All Sioux Air Tools are manufactured to extremely close tolerances. Reasonable care and preventative maintenance will greatly prolong
their service life.
This line of tools is designed for a long life of continuous duty on assembly lines, with a minimum of service and maintenance. Rotating
parts are mounted on extra-capacity ball bearings, rotors and spindles are finished to extreme accuracy for power and low air con-
sumption, gears and pinions are oversize and correctly hardened for quietness and long life.
Special attention has been given to ease of servicing. These tools can be disassembled and reassembled with ease.
Before connecting the tool, blow the air line to remove water and dirt which may have accumulated. This is especially important for a
new line or when the line has not been used for some time.

GEARS

The gears are lubricated at the factory. Every 100 hours of operation add 1/4 oz. of Sioux Grease No. 289A.

AIR MOTORS

Sioux Air line lubricators are recommended. When used, adjust lubricator to deliver 2 to 4 drops of Sioux Air Motor Oil No. 288 per
minute to the air tool. If tool is not used with a lubricator, place 10 to 15 drops of Sioux No. 288 oil into air inlet twice daily.

SCREW DRIVER AND NUT RUNNER CLUTCHES

Lubricate every 40 hours using No. 1232A Sioux Grease on the clutch jaws and bearing surfaces.

OPERATION

The air motor is started by depressing the operating lever or trigger. Motor speed may be controlled by adjusting the slotted head
control which is located on the tool housing or, on some models, on the trigger surface.
If the tool is equipped with reversing button, always depress the button fully to obtain maximum power.
Air supply hose should not be less than 3/8" I.D. If extension hose is necessary, use 1/2" I.D. hose, with couplings not less than 3/8 I.D.
1. Keep Work Area Clean: Cluttered areas and benches invite accidents.
2. Wear Proper Apparel: No loose clothing or jewelry to get caught in moving parts.
3. Use Safety Glasses: Protect your eyes.
4. Secure Work: Use clamps or vise to hold work. Its safer than using your hand and it frees both hands to operate tool.
5. Don't overreach: Keep proper footing and balance at aIl times.
6. Maintain Tools With Care: Keep tools sharp and clean for best and safest performance. Follow instructions for lubricating and
changing accessories.
7. Disconnect Tools: When not in use, before servicing, when changing accessories such as blades, bits and etc.
8. Remove Adjusting Keys and Wrenches: Form habit of checking to see that keys and adjusting wrenches are removed from tool
before turning it on.
9. Caution: The use of an accessory with this tool not provided or specified by SIOUX TOOLS INC. may be hazardous.
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
El polvo generado al lijar, aserrar, afilar, taladrar y realizar otras tareas de
construcción contiene sustancias químicas que podrían causar cáncer,
malformaciones congénitas y otras alteraciones del aparato reproductor.
INSTRUCTIONS FOR
NO. 2 1/2 SERIES TOOLS

BE SURE TO LUBRICATE

SAFETY PRECAUTIONS

other reproductive harm.
1
Form A854
Date 3-02/A
Page 1 of 2
Printed In U.S.A.
