Read and understand "Safety Instructions For Air Tools" and these instructions before
Tools left connected to the air supply while making adjustments, changing accessories, or doing any maintenance or service on tool can
Always remove tool from air supply and activate trigger to bleed air line before making any adjustments, changing
AIR SUPPLY
The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter, pressure regulator,
and lubricator will insure maximum output and service life of tools.
HOSE AND HOSE CONNECTIONS
Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 3/8" (10mm) I.D. Use couplings and fittings with at
least 1/4" (6.4mm) I.D.
LUBRICATION
An airline lubricator, set to deliver one drop per minute, is recommended. If a lubricator is not used, add .04 oz. (1.2cc, 12 to 15 drops) of
SIOUX No. 288 air motor oil into the air inlet daily.
Lubricate the planetary gearing every 150 hours of operation with SIOUX No. 1232A grease. Lubricate the angle head every 8 hours with
Sioux No. 1232A grease. Lubricate positive and adjustable clutches every 25 to 50 hours with SIOUX No. 1232A grease.
INSTRUCTIONS FOR NO. 1 SERIES
"1AM" ANGLE TOOLS
operating this tool.
start unexpectedly.
accessories, or doing any maintenance or service on tool.
Tools starting unexpectedly can cause injury.
SOUND AND VIBRATION READINGS
Catalog No.
*Sound Pressure dBA
1AMX1201
72.3
1AMX1206
72.3
1AMX2106
71.5
1AM1102
72.3
1AM1106
72.3
1AM1111
72.3
1AM1112
72.3
1AM1206
72.3
1AM1211
72.3
1AM1311
72.3
1AM1402
72.3
1AM1411
72.3
1AM1412
72.3
1AM1413
72.3
1AM1511
72.3
1AM1512
72.3
1AM1513
72.3
1AM1611
72.3
1AM1711
72.3
1AM1712
72.3
1AM1713
72.3
1AM2101
71.5
1AM2105
71.5
1AM2106
71.5
1AM2201
71.5
1AM2202
71.5
1AM2205
71.5
1AM2206
71.5
1AM2301
71.5
1AM2302
71.5
1AM2305
71.5
1AM2306
71.5
1AM2401
71.5
1AM2402
71.5
1AM2405
71.5
1AM2406
71.5
*per PN8NTC1
*Sound Power dBA *Vibration m/s
83.7
83.7
Less than 2.5
82.3
Less than 2.5
83.7
83.7
Less than 2.5
83.7
83.7
83.7
Less than 2.5
83.7
83.7
83.7
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
83.7
Less than 2.5
82.3
82.3
Less than 2.5
82.3
Less than 2.5
82.3
82.3
82.3
Less than 2.5
82.3
Less than 2.5
82.3
82.3
82.3
Less than 2.5
82.3
Less than 2.5
82.3
82.3
82.3
Less than 2.5
82.3
Less than 2.5
*per PN8NTC1
*per ISO 8662
1
Form ZCE509
Date 2003June24/C
Page 1 of 16
2
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Printed In U.S.A.
