INSTRUCTIONS & PARTS LIST FOR NO. 1 SERIES
Read and understand "Safety Instructions For Air Tools" and these instructions before
Tools left connected to the air supply while making adjustments, changing accessories, or doing any maintenance or service on tool can
Always remove tool from air supply and activate trigger to bleed air line before making any adjustments, changing
AIR SUPPLY
The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter, pressure
regulator, and lubricator will insure maximum output and service life of tools.
HOSE AND HOSE CONNECTIONS
Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 3/8" (10mm) I.D. Use couplings and
fittings with at least 1/4" (6.4mm) I.D.
LUBRICATION
An airline lubricator, set to deliver one drop per minute, is recommended. If a lubricator is not used, add .04 oz. (1.2cc, 12 to 15
drops) of SIOUX No. 288 air motor oil into the air inlet daily.
Lubricate the gearing every 150 hours of operation with SIOUX No. 1232A grease. Lubricate positive clutch every 25 to 50 hours
with SIOUX No. 1232A grease. Lubricate torque control clutches every 25 to 50 hours with light oil.
"1ST" and "1OT" PUSH TO START TOOLS
SERIAL "C"
operating this tool.
start unexpectedly.
accessories, or doing any maintenance or service on tool.
Tools starting unexpectedly can cause injury.
SOUND AND VIBRATION READINGS
Catalog No.
*Sound Pressure dBA
1OT1108, 1OTY1108
1OT1208, 1OTY1208
1OT1308, 1OTY1308
1OT1508, 1OTY1508
1OT2108, 1OTY2108
1OT2208, 1OTY2208
1OT2308, 1OTY2308
1OT2508, 1OTY2508
1ST1108, 1STY1108
1ST1208, 1STY1208
1ST1308, 1STY1308
1ST1508, 1STY1508
1ST2108, 1STY2108
1ST2208, 1STY2208
1ST2308, 1STY2308
1ST2508, 1STY2508
*per PN8NTC1
*Sound Power dBA
73.9
85.23
73.9
85.23
73.9
85.23
73.9
85.23
73.18
85.11
73.18
85.11
73.18
85.11
73.18
85.11
72.26
83.68
72.26
83.68
72.26
83.68
72.26
83.68
71.46
82.88
71.46
82.88
71.46
82.88
71.46
82.88
*per PN8NTC1
1
Form ZCE427A
Date 2003June17/E
Page 1 of 20
*Vibration m/s
2
Less than 2.50
Less than 2.50
Less than 2.50
Less than 2.50
2.95
2.95
2.95
2.95
13.21
13.21
13.21
13.21
13.7
13.7
13.7
13.7
*per ISO 8662
Printed In U.S.A.
