12-24 Screw
(4 places)
™
MRJ21
Receptacle
(8 places)
Figure 1
(1-1671594-1 panel with AMPTRAC Cassette 2153091-1 and Standard Cassette 2153115-1 as shown. Use
1.
INTRODUCTION
MRJ21 10GbE Quick Fit Cassette 8 Ports are designed to be mounted onto UCP Patch Panels
(angled or flushmount) as shown in Figure 1 and the AMPTRAC version is designed to be used with
AMPTRAC system.
Read these instructions thoroughly before starting installation.
Learn more about at: http://www.ampnetconnect.eu
NOTE
All numerical values in this instruction sheet are in metric units [WITH U.S. customary units
in brackets]
NOTE
These instructions assume that reader understand the operation of equipment and software
used with the AMPTRAC system (not shown).
To obtain information on CommScope
®
contact your local CommScope
account
™
representative, PartnerPRO
Network Partner
or visit our website at
www.commscope.com
Instruction
Sheet
™
MRJ21
10GbE Quick Fit Cassette 8 Ports
Front of UCP Panel
Port
identification
label
appropriate customer drawing for other panel views)
™
MRJ21
10GbE 8 Port Quick Fit Cassette
2153091-1 With AMPTRAC
©2016 CommScope, Inc.
®
products,
All Rights Reserved
™
AMPTRAC
Sensor PCB
2153115-1 Without AMPTRAC
This product is covered by one or more U.S.patents
or their foreign equivalents. For patents, see
www.commscope.com /ProductPatent/ProductPatent.aspx
411-93028
Dec. 2016
Rev C
1x8 RJ45 Connector
Cassette (4 places)
™
AMPTRAC
Upgrade HDP-22
conn. location
1 of 4
