Course Deviation Indicator (CDI) scale is displayed at the bottom of the screen. Use the cur-
sor keys up/down to change VSI scale among 250, 500 and 1000 FT. Use the cursor keys
left/right to change CDI scale among 0.1, 0.5, 1, 2, 5 and 10 NM.
The units of measure are selected from Units Setup in the System Setup Menu, (refer
to Chapter 14).

5.2 HSI MENU

When on the HSI screen, pressing 'MENU' will access the HSI Menu with the following options:
Add Mark under Fix, Setup Data Fields, Default Data Fields and Compass Orientation.

5.2.1 ADD MARK UNDER FIX

While in HSI mode, it is possible to create a User Mark under the current position fix. From
the HSI screen:
>'MENU' + "ADD MARK UNDER FIX" + 'ENTER'
An information box will appear confirming the creation of the User Waypoint and
informing of the default name applied by the software; press 'ENTER' to accept. To edit this
Mark see Par. 8.1.3 and Par. 8.2.2.

5.2.2 SETUP DATAFIELDS

The HSI Data Window can be customized by the user to display navigational data required for
his flight; similar to the Moving Map Data Window (see Par. 3.2). You can edit the data fields
from the HSI page:
>'MENU' 1 sec. + "HSI SCREEN" + 'ENTER' + 'MENU' + "SETUP DATA FIELDS..." +
'ENTER'
After pressing 'ENTER' a box in the Data Window will be highlighted. Select the box
to be edited and press 'ENTER'. The OPTIONS box will appear allowing you to select the
item to display in this box. Once selected, press 'ENTER' to accept.
You can then scroll to another box and proceed as above. Once all boxes are set up,
press 'ESC' to exit.

5.2.3 DEFAULT DATAFIELDS

This will restore the data field settings to the default values of Track (TRK), Ground Speed
(GS), To Descent, Distance (DST), Estimated Time Enroute (ETE) and Altitude (ALT).
From the HSI screen:
