• Track Download
Auxiliary Memory
• User Cartridge 1MB (about 52,000 Track points; 26,000 User Points available)
Interface
• Two I/O ports

1.1.3 PHYSICAL CHARACTERISTICS

EKP-III size (inch/mm)
• 6" x 2.6" x 9.4" (150.5 mm x 66.4 mm x 239.5 mm)
EKP-III weight
• (800 g)
LCD display
• monochromatic 7.2"; color TFT 6.4"
• resolution 640 x 480 pixels
Antenna dimensions
• 3" diameter, 0.625" height (76.2 mm diameter, 15.9 mm height)
Antenna includes a 5 meter cable
Power consumption
• monochromatic: 7 Watt, 10–35 Volt DC; color 10 Watt, 10–35 Volt DC
Operating Temperature Range
• 32°F to 131°F (0°C to 55°C)
Storage Temperature
• -13°F to 158°F (-25°C to 70°C)
Memory
• Non volatile with battery back-up
Keyboard
• Backlighted, silicon rubber

1.2 BASIC

The EKP-III is controlled by using 12 keys. As you press a key, a single audio beep confirms
the key action; every time the key pressed is not valid, three rapid beeps sound indicating that
no response is available.
POWER Key - For quick access to the GPs status tap the POWER key. The Brightness and
contrast will appear; the GPS status and current time are displayed at the bottom of this box
