Steelcase Verb Active Media Table Manual page 19

®
43" Table, Monitor to Lift Column Installation
IMPORTANT: Select hanger bracket hooks that
will ensure monitor screen is installed at proper
height. Align monitor screen, horizontally, on
screen back plate. Make sure that both hanger
brackets are fully engaged and that two (2) screen
locks are installed.
MONITOR SCREEN WITH
VERTICAL HANGER BRACKETS
4
SCREEN LOCK (X2)
3
SCREEN BACK PLATE
1
CAUTION: Use care when lowering the lift column
with mounted monitor screen for the first time. Check
to ensure that no interference will occur between the
monitor screen and cabinet structure.
TOP
HANGER BRACKETS
2
END VIEW
Page 19 of 60
1094808001 Rev C
