Installing Monitor Mounting Components for 43" Tables
(Continued)
NOTE: Using the up/down switch, extend the lift column
to full height to ease installation of monitor.
IMPORTANT:
Make sure the articulating wire
manager is installed and used to contain moving wires to
prevent wire pulling or pinching.
x1
.750"
(19.1 mm)
4a
x1
ARTICULATING
WIRE MANAGER
0.472"
(12.0 mm)
mechanism to open lift automatically.
MONITOR SUPPORT
ASSEMBLY
4b
M6
IMPORTANT:
Plastic cover must be installed for lift
2
x2
0.630"
(16.0 mm)
M6
CABLE
CLIPS
3
Page 17 of 60
1094808001 Rev C
