HPRT TP80 Series Ethernet Connection Manual

Hide thumbs Also See for TP80 Series:

Advertisement

Quick Links

Ethernet Connection Manual
TP80 SERIES
Rev.1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP80 Series and is the answer not in the manual?

Questions and answers

Related Manuals for HPRT TP80 Series

Summary of Contents for HPRT TP80 Series

  • Page 1 Ethernet Connection Manual TP80 SERIES Rev.1.0...

  • Page 2: Table Of Contents

    CONTENT Introduction ......................1 1. Connected directly by Ethernet cable .............. 2 2. Connected by Router ..................8 3. Connected by Driver ..................21 4. Connected by Website ................... 31...

  • Page 3: Introduction

    Introduction This manual content may be changed without permission and our company reserve the rights to make changes in technology, spare parts, hardware and software of the products. Please contract our company, if the user needs further information about the products. Without any written permission from our company, any section of this manual is prohibited to be copied or transferred in any form.

  • Page 4: Connected Directly By Ethernet Cable

    1. Connected directly by Ethernet cable Connect the printer at one end of the network cable and the other end to the computer in the following ways: ▉ Modify the computer IP address 1）Open the printer tool software and select the current printer model. (Take TP80BE as an example) Note: The current computer is disconnected from the Internet...
  • Page 5 Click "Printer Test", select "Self Test", you can view the printer IP address from the Self-test page. For example, from the following Self-Test page information can know that the printer IP address is: 10.0.16.40. SELF-TEST Brand: HPRT MODEL: TP80BE FW Version: SV1 .00. 05 CG Version: SV1 .00.
  • Page 6 ￭ Right-click the network and select “Properties”. ￭ Double-click "TCP/IPv4" to enter the computer IP address modification page.
  • Page 8 ￭ Change the COMPUTER address (for example, 10.0.16.33) so that the COMPUTER IP address is in the same network segment as the printer IP address, and in the figure, click OK. 4) After the COMPUTER re-recognizes the IP address, return to the main menu page of the tool and click "Modify Printer".
  • Page 9 5) Modify the “portInfo” to TCP/IP, and modify the IP address to the printer current IP address, and click OK. 6) Return to the main page of tool menu and click "Connection Test". When pop up the following "connection succeeded" means that the printer is connected to the computer.

  • Page 10: Connected By Router

    2. Connected by Router When the printer and the computer are connected to the same router, the operation is as follows: ▉ One: Modify the printer IP address 1）View the computer IP address in the following ways: ￭Click "Start" and select "Run". ￭Input “cmd”...
  • Page 11 ￭ You can view the IP address of your computer by entering “ipconfig + enter”. (For example, the computer IP address is: 10.021.162)
  • Page 12 2）Open the printer tool software and select the current printer model. (Take TP80BE as an example)
  • Page 13 3) Click “Advanced Settings” to select “Ethernet setting”. 4) Select static “Static IP mode or Auto assignment IP” (Note: “Auto assignment IP” mode is the router is automatically assigned with the printer).
  • Page 14 5）Set the printer IP address to the same network segment as the computer, click “Set”, and restart the printer. Note: The same network segment refers to the first three digits are same, the last value is not the same. And the value change range is "1~255".
  • Page 15 3）Return to the main menu page of the tool and click "Modify Printer". 4) Modify the “portInfo” to TCP/IP and modify the IP address to the printer current IP address, and click OK.
  • Page 16 5) Return to the main page of tool menu and click "Connection Test". When pop up the following "connection succeeded" means that the printer is connected to the computer.
  • Page 17 ▉ Two: Modify the computer IP address 1）Open the printer tool software and select the current printer model.
  • Page 18 2) Click "Printer Test", select "Self Test", you can view the printer IP address from the Self-test page. For example, from the following Self-Test page information can know that the printer IP address is: 10.0.16.40. SELF-TEST Brand: HPRT MODEL: TP80BE FW Version: SV1. 00. 05 CG Version: SV1.
  • Page 19 ￭Right-click the network that is currently connected to the printer and click “Properties”. ￭Double-click "TCP/IPv4" to enter the computer IP address modification page.
  • Page 20 ￭Select “Use the following IP address” to set the computer IP address to be in the same network segment as the printer IP address; In the following, click OK. Note: The same network segment refers to the first three digits are same, the last value is not the same.
  • Page 21 4) After the COMPUTER re-recognizes the IP address, return to the main menu page of the tool and click "Modify Printer". 5) Modify the “portInfo” to TCP/IP and modify the IP address to the printer current IP address, and click OK.
  • Page 22 6) Return to the main page of the tool menu and click "Connection Test". When pop up the following "connection succeeded" means that the printer is connected to the computer.

  • Page 23: Connected By Driver

    3. Connected by Driver 1) Install the printer driver. (Take TP80BE as an example) 2) Print the Self-test page through the tool software to get the printer IP address. (For example, the printer IP address is: 192.168.1.99) 3) When the drive installation is completed, click "Start" and select "Device & amp; printer".
  • Page 24 4）Right-click the current printer and select “Printer properties”.
  • Page 25 5）Click “Port”.
  • Page 26 6）Click “Add Port”.
  • Page 27 7）Select “Standard TCP/IP Port”, and then click “New port”. 8）Click “Next”.
  • Page 28 9）Enter the printer name or IP address and click “Next”.
  • Page 29 10）Click “Next”.
  • Page 30 11) Click “Next”.
  • Page 31 12) Return to the port page, select the port you have added, and click “Apply”.
  • Page 32 13）Click “General”, and select “Print test page” to test whether the printer is connected to the computer.

  • Page 33: Connected By Website

    4. Connected by Website 1） Connect the printer to your computer. 2） Select one of the above Ethernet connections to connect the printer to your computer. 3） Print the Self-test page through the tool software to get the printer IP address. (For example, the printer IP address is: 10.0.21.31) 4）...
  • Page 34 6） Input "Ping 10.0.21.31 enter" to check if the printer and computer are connected successfully. 7）Open the browser and input the URL: 10.0.21.31 enter, as shown in the figure.
  • Page 35 8）Click "Information"-"TCP/IP" to view the current printer IP. 9）Click "Configuration"-"TCP/IP"-To modify the printer IP address.
