Quick Start Guide
TP809
Xiamen Hanin Electronic Technology Co.,Ltd
ADD:
Room 305A,Angye Building,Pioneering Park,
Torch High-tech Zone,Xiamen,China.
TEL:
+86-(0)592-5885993
FAX:
+86-(0)592-5885992
WEB:
www.hprt.com
Appearance and Components
Front
LED Panel
Top Cover Open Button
Power button
Rear
Ethernet interface
USB interface
Serial interface
Inside
Printer Cover
Feed button
Power Supply interface
Cash drawer interface
Packing List
Printer
Serial Cable
Power Adapter
CD
Quick Start Guide
！
Notes:
1.The packing materials are actually dependent on the order.
2.The power adapter and power cord vary by local or region.
Paper Installation
1.Press the top cover open button to open the printer cover.
2.In the correct direction of the roll paper,install the roll paper.
Thermosensitive layer
USB Cable
Power Cord
Roll Paper
Advertisement
Table of Contents
Related Manuals for HPRT TP809
Summary of Contents for HPRT TP809
- Page 1 Packing List Quick Start Guide Printer USB Cable Power Cord TP809 Serial Cable Power Adapter Roll Paper Quick Start Guide Xiamen Hanin Electronic Technology Co.,Ltd ADD: Room 305A,Angye Building,Pioneering Park, Torch High-tech Zone,Xiamen,China. ！ Notes: TEL: +86-(0)592-5885993 1.The packing materials are actually dependent on the order.
- Page 2 Power Supply 3.Pull out some roll paper, and close the printer cover. 1.Connect power adapter with printer. 2.Connect power adapter with power cord. 3.Plug the other side of power cord into the socket outlet. 4.Tear the extra paper of the printer. Power Adapter Power Cord Interface...
