- Page 1 Net Configuration Tool Manual TP80 Series Rev:1.0...
- Page 2 CONTENT 1. Statement............................3 2. Printer Connecting..........................4 3. Set the IP Address for Printer......................4 4. Configurate the Net Tool........................9...
-
Page 3: Statement
TP80 Series Net Configuration Tool ● 1. Statement This manual content shall not be changed without permission and our company reserve the rights to make changes in it. Please contract our company, if the user needs further information about the products. Without any written permission from our company, any section of this manual is prohibited to be copied or transferred in any form. -
Page 4: Printer Connecting
TP80 Series Net Configuration Tool ● 2. Printer Connecting ● Check the printer is switched on. ● Make sure that the printer is on the same LAN as the computer (for example, connect to the same router access point). 3. Set the IP Address for Printer ●... - Page 5 TP80 Series Net Configuration Tool ● ● Click the Advanced Settings, then click the Ethernet Setting.
- Page 6 TP80 Series Net Configuration Tool ● ● Ethernet Setting Note: This setting includes Auto assignment IP and Static IP mode, choosing one of the modes to connect). Auto assignment IP: this mode automatically assigns the IP address to the printer. After setting,...
- Page 7 TP80 Series Net Configuration Tool ● Static IP mode: Change the printer IP address to make the IP address of the printer is the same segment as the IP address of the host. Printer IP address：(Such as: 192.168.0.33) Check IP address of the PC: (Such as: 192.168.1.13)
- Page 8 TP80 Series Net Configuration Tool ● Change IP address of the printer：...
-
Page 9: Configurate The Net Tool
TP80 Series Net Configuration Tool ● 4. Configurate the Net Tool ● Double click the “HPRTNetWorkUtilityForPOS VX.X.X.X”，then double click .exe software to run it in the host. ● Open the tool, then click the “Scan the printer” to identify printers that are on the same LAN as the... - Page 10 TP80 Series Net Configuration Tool ●...
- Page 11 TP80 Series Net Configuration Tool ● ● Click the printer name to see the printer information in the lower-left corner. Such as: TP808.
- Page 12 TP80 Series Net Configuration Tool ● ● Click the printer information, you can modify the print name, IP address, Subnet Mask, Gateway and dynamic or static IP (DHCP), then click "Set". Such as: 808. Note: 1. After making changes to the port parameters, you need to restart the printer 2.
- Page 13 TP80 Series Net Configuration Tool ● ● Check the Status Monitoring to monitor the current status of the printer and set the monitoring interval. For example, the interval is set to 10 seconds, and the tool scans the current state of the printer every 10 seconds.
- Page 14 TP80 Series Net Configuration Tool ● ● If the printer is in an unusual state, the exception message pops up in the lower-right corner of the computer screen. Note: Restart Printer: This feature is only available for TP808. Paper Cut: This feature is only available for models with cutters.
