modway MOD-5357 Manual page 2

BED FRAME
STEP 1:
Put 1 piece of Short Board (1) upside down on a carpeted or padded area by two adults
Insert 1 piece of Leg (6) and 1 piece of Leg (5) into the Short Board (1) as shown.
Secure them by using 4 pieces of Bolt (A) and 4 pieces of Flat Washer (D).
Use Allen Wrench (G) to tighten the Bolts (A) clockwise until secure.
Repeat the same steps for the remaining 1 piece of Short Board (1), 1 piece of Leg (5) and 1 piece of Leg (6).
G
A
D
6
Ax8
STEP 2:
Place 1 piece of Long Board (2) to 2 pieces of assembled Short Board (1) by two adults
Attach them by using 4 pieces of Bolt (B),4 pieces of Spring Washer (F) and 4 pieces of Flat Washer (E) as shown.
Use Allen Wrench (H) to tighten the Bolts (B) clockwise until secure.
Repeat the same steps for the remaining 1 piece of Long Board (1).
1
Bx8 Ex8
Customer Service 908-368-1025︱
1
6
Dx8 Gx1
2
Fx8
1
2
1
Hx1
5
Hardware & Tool required
2
1
E
F
B
H
Hardware & Tool required
Page 2 of 6
