modway MOD-6146 Quick Start Manual

MOD-6146/6147
Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 35 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Component:
A. HEADBOARD
B. HEADBOARD LEG (L)
C. HEADBOARD LEG (R)
D. HEADBOARD SUPPORT RAIL
E.
FOOTBOARD
F.
SIDE RAIL (L)
G. SIDE RAIL (R)
H. CENTER SUPPORT WOOD
I. CENTER LEG
J. BED LEG
x 1
x 1
x 1
x 1
x 1
x 2
x 2
x 4
x 4
x 4
Hardware:
1
JCBC BOLT M6 x 20mm
2
JCBC BOLT M6 x 30mm
3 JCBC BOLT M6 x 35mm
4 JCBB BOLT M8 x 50mm
5
SPRING WASHER M6
6 FLAT WASHER M6
7 SPRING WASHER M8
FLAT WASHER M8
8
9 ALLEN KEY (BALL SHAPE) M4
10 ALLEN KEY (BALL SHAPE) M5
11 SHEET METAL (VMB 3076)
H
I
B
F
F
E
J
4 PCS
16 PCS
12 PCS
6 PCS
20 PCS
20 PCS
6 PCS
6 PCS
1 PC
1 PC
2 PCS
A
D
C
G
G
01 of 07
