Mounting the Antenna
Attach the antenna by using the hex head bolts (M8X35L), M8 spring
washers, and M8 flat washers supplied.
Figure 12 : Mounting the Antenna
16
Installing the ACU
ACU Dimensions
Radome Base
Deck
M8 Flat Washer
M8 Spring Washer
M8 Hex. Bolt
13mm Spanner
22.8 cm (9")
17.8 cm (7")
5.5 cm (2.2")
Figure 13 : Dimension of ACU
5.4 cm (2.1")
