Monitoring the Current Status of the Antenna
While POWER ON to Intellian Inland, ACU displays the status of the antenna. The various
ACU displays may be shown according to the current status of the antenna.
SEARCH A: DTV101
B:DTV119 SETUP
ANTENNA IS UNWRAPING
B:DTV119 SETUP
26
1. The antenna is searching Satellite A.
2. The antenna is tracking Satellite A.
3. The antenna is winding/unwinding the cables in
the antenna.
4. The antenna is again tracking Satellite
A. Press center soft key to display
position detail.
5. Antenna position detail and signal strength are
AZ : ###.# EL : ##.#
displayed.
SIGNAL : ### ● [VL]
6. Press center soft key to display current GPS
information. Press center soft key to return to
main tracking mode.
