EbV
INFO TIME
OFF
5.1.2.8

"Emission Measurement / Manual Mode" Key

5.1.2.8.1 Emission Measurement (may only be carried out by the heating specialist).
CAUTION
¡
CAUTION
Function:
Application:
Termination:
Automatic return
If the "information key" ¤ is pressed for approx. 3 s upon accessing the information
level, the INFO TIME parameter appears.
This parameter determines the time for the automatic return to the standard display.
Factory preset:
Setting range
OFF No exit, the last information displayed remains
until the next setting on the display.
Note: Malfunction messages
1...10min Automatic exit from the information level after
the specified time, settable in 0.5 minute steps.
Emission Measurement has to be carried out by a technician.
By pressing this key, the heat generator runs for 20 minutes at the set maximum
temperature limit. The remaining time is displayed as it passes.
Both stages of two-stage heat generators are in operation (measurement with
nominal capacity).
Danger of scalding because the DHW temperature may exceed the defined
DHW setpoint.
The heat generator is adjusted to the maximum H-GEN temperature. All heating
circuits and DHW heating adjust their nominal value to the corresponding maximum
temperature.
Emission measurement by the technician
The emission measurement can be terminated prematurely at any moment using the
¡
key.
Product documentation THETA NORM/UNIT
OFF
OFF, 1...10 min
5-15
