5.4.4
SouthBridge VIA VT8237A Configuration
Serial Port1 Address
Serial Port1 Mode
Serial Port2 Address
Serial Port2 Mode
Parallel Port Address
Parallel Port Mode
Parallel Port IRQ
OnChip SATA-IDE
Azalia Audio
Onboard LAN
OnBoard LAN Boot ROM
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial Port1 Mode [Normal]
Allows you to select the Serial Port1 mode.
Configuration options: [Normal] [IrDA] [ASK IR]
Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to select the Serial Port2 mode.
Configuration options: [Normal] [IrDA] [ASK IR]
ASUS V-Series M2V890
[3F8/IRQ4]
[Normal]
[2F8/IRQ3]
[Normal]
[378]
[Normal]
[IRQ7]
[IDE]
[Enabled]
[Enabled]
[Disabled]
5-21
