3.3 Motherboard layout

PS/2
IOC_MB
T:Mouse
B:Keyboard
VGA1
ATX12V1
Line
Out
Line
In
Mic
In
RJ-45
LANLED
USBPWR_12
USB
T:Port2
B:Port1
LAN
CHIP
AUX1
Audio
Codec
MODEM1
MDC1
CD1
ASUS Terminator P4 533A Barebone System
23cm (9.06in)
Super
Flash
I/O BIOS
DDR DIMM2 (64/72-bit, 184-pin module)
DDR DIMM1 (64/72-bit, 184-pin module)
Socket 478
Accelerated Graphics Port
(AGP)
PCI Slot 1
ASUS
Mozart USBPWR_34
MIC_LOUT1
FLOPPY1
CHA_FAN1
P4SC-EA
SiS
651
HOST/
Memory
Controller
®
Chipset
CR2032 3V
Lithium Cell
CMOS Power CLRTC1
USBPWR_56
USB_34 USB_56
SiS
962L
BUZZER1
IDE_LED1
PANEL1
39
