Internal Features
The figure below shows the internal view of the system when you remove
the cover and flip out the drive frame. The standard components already
installed in the system and the locations of the available drive bays are
pointed out.
NOTE
The system may come with either a PFC (Power Factor Correction) or
non-PFC power supply.
Game/MIDI/COM1
Extension Module
Modem Card
(optional)
14
Two 5.25" Drive Bays
(Optional CD-ROM)
Motherboard
USB/audio
Board
Chapter 1: System Introduction
3.5" HDD
Drive Bay
3.5" Floppy Drive
PFC Power Supply
Non-PFC
Power Supply
