2.8 Install an expansion card

The motherboard has one 32-bit PCI slot and one Accelerated Graphic
Port (AGP) slot.
Follow these steps to install a PCI
or AGP card.
1. Place the chassis on its side.
2. Remove the metal bracket
opposite the slot that you wish
to use.
3. Align the card golden fingers
to the slot and its metal
bracket to the slot opening on
the chassis.
4. Press the card firmly until it is
properly seated on the slot.
5. Secure the card to the chassis
with a bracket screw.
NOTE
If your system came with the optional modem card, the PCI slot is
already occupied.
28
Metal Bracket PCI Slot (PCI1)
AGP Slot (AGP1)
