Johnson Controls Metasys FEC Series Installation Manual page 13

Field equipment controller
Table of Contents

Advertisement

Table 5: Termination details
24 VAC Binary Output
(Switch High, Externally
Sourced)
Incremental Control to
Actuator (Switch Low,
Externally Sourced)
Incremental Control to
Actuator (Switch High,
Externally Sourced)
Network Stat with Phone
Jack (Fixed Address = 199)
Network Stat with Terminals
Addressable
Type of Input/
Termination diagrams
Output
BO
BO
BO
SA Bus
SA Bus
Metasys System FEC1611 and FEC1621 Field Equipment Controller Installation Guide
13
