treesse Fusion Spa 200 Preinstallation Manual page 14

Pre-Installation
D
2 Ø15 cm vents to ensure
proper ventilation of the
technical compartment
A
Technical compartment for
maintenance of operational
components: plan for 50 cm
on all sides of the minipool
CONCRETE SLAB h. 10 cm minimum
D
See the plumbing
and electrical
preparations on
page 15 and 23.
B
Internal drainage
grates
2 Ø15 cm vents to ensure
proper ventilation of the
technical compartment
CONCRETE SLAB h. 10 cm
minimum
EN
C
Non-slip flooring
Technical compartment for maintenance
A
of operational components: plan for 50
cm on all sides of the minipool
14
Fusion
minipool
C
Non-slip flooring
E Insulation: prevents
damage from freezing
and condensation
See the plumbing
and electrical
preparations on
page 15 and 23.
B
Internal drainage
grates
(measurements in cm)
E Insulation:
prevents damage
from freezing and
condensation
