Task Force Tips MONSOON Instructions For Installation, Safe Operation And Maintenance page 27

DESCRIPTION
#
1 CABLE - POWER & COMM.
2 1/4-20 X 1/2 BUTTON HEAD SCREW
3 .375 OD LOOP CLAMP STAINLESS
4 LOWER WIRE SKIRT
5 UPPER WIRE SKIRT
6 5/16" SS BALL
10 1/4-28 X 1/2 SOCKET HEAD SCREW
CONTROL BOX BRACKET
11
CONTROL BOX BRACKET FOR LADDER & PLATFORM
13 MAIN MONITOR CONTROL BOX
14 .250 OD LOOP CLAMP STAINLESS
15 10-32 X 3/8 BUTTON HEAD SCREW
GEAR MOTOR SUBASSEMBLY
20
(#20 Contains Items #21 Thru #32, Except #27))
21 CUP SEAL
22 6-32 X 5/16 LONG SHCS WITH HEAD SEAL
23 MOTOR SOCKET
24 O-RING-038
25 GEAR MOTOR WITH ENCODER
26 ENCLOSURE
30 O-RING-018
31 CONDUIT FITTING
32 HOSE - 3/8" ID PUSH-LOK
34 OVERRIDE KNOB
35 WIRE SKIRT RETAINER
34 OVERRIDE KNOB
35 WIRE SKIRT RETAINER
VO-RING-244
36
VO-RING-236
4" MONITOR BASE CLAMP
37
3" MONITOR BASE CLAMP
38 WASHER
39 10-24 X 1 1/4 SOCKET HEAD SCREW
40 CYLINDER NUT
©Copyright Task Force Tips, Inc. 2004-2011
QTY
30'
12
1' *
* Length Depends on Confi guration.
27
PART #
Y5200
3 VT25-20BH500
3 Y4655
1 Y4660
1 Y4650
1 VB.312
VT25-28SH500
1 Y4618
1 Y4619
1 SEE SECTION 9.1
2 Y4656
1 VT10-24BH375
2 Y4950
1 Y4620
4 VT06S32SH312
1 Y4615
1 VO-038
1 Y4611
1 Y4616
1 VO-018
1 Y5213
Y5250
2 Z245
2 Y4661
2 Z245
2 Y4661
VO-244
1
VO-236
Y4435
2
Y4436
2 VW360X200-04
2 VT10-24SH1.2
2 Y4437
LIY-200 May 24, 2011 Rev10
