Task Force Tips MONSOON Instructions For Installation, Safe Operation And Maintenance page 25

# DESCRIPTION
BASE CODE-RPF 4" -ALUMINUM
1
BASE CODE-RLF 3" -ALUMINUM
2 O-RING-350
3 LOWER SEGMENT
4 1/4-28 X 1/2 SOCKET SET SCREW
5 1/4-28 X 1/4 SOCKET SET SCREW
6 BLACK DOME PLUG
10 7/16" TORLON BALL (32) PER RACE
11 BALL PORT PLUG
12 1/4" NPT PLUG
13 DOWEL PIN
14 LOWER SHROUD
15 O-RING-245
16 LOWER RING GEAR
20 MIDDLE SEGMENT
21 UPPER RING GEAR
22 UPPER SEGMENT
23 UPPER SHROUD
24 1/4-20 X 3/8 BUTTON HEAD SCREW
25 BALL 7/16" TORLON
26 1/2-20 X 3/8 SOCKET SET SCREW
30 HALF RING GEAR
31 5/16-18 X 1/2 SOCKET HEAD SCREW
32 3/16" TORLON BALL
33 PINION
34 PLUG 2-1/4 MOUNTING HOLE
35 5/16" TORLON BALL (49) PER RACE
36 3/8-24 X 5/16 SOCKET SET SCREW
40 HEADED BUSHING
41 DRIVE SHAFT
42 KEY
43 SPACER
44 12 DP WORM
45 BEARING
46 WASHER
50 E-CLIP 5/8" EXTERNAL
51 SNAP RING
52 COVER PLATE
53 KNOB
54 WASHER
55 HANDWHEEL
56 CRANK BUSHING
57 3/8-16 X 1-1/2 BUTTON HEAD SCREW
60 HANDWHEEL LABEL; DOWN <-> UP
62 NAME LABEL: MONSOON
63 SHAFT SPRING
64 WASHER
62 NAME LABEL: MONSOON (MANUAL MODEL)
63 SHAFT RING
64 WASHER ACETAL
65 3/8-24 X 3/8 SOCKET SET SCREW
VO-RING-244
66
VO-RING-236
4" MONITOR BASE CLAMP
67
3" MONITOR BASE CLAMP
68 WASHER
69 10-24 X 1 1/4 SOCKET HEAD SCREW
70 CYLINDER NUT
71 CRANK
72 HANDLE LABEL - WHITE
©Copyright Task Force Tips, Inc. 2004-2011
QTY
1
1
1
4
2
3
64
1
1
1
1
2
1
1
1
1
1
6
32
1
1
2
146
1
1
98
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
1
1
2
2
1
1
1
5
1
2
2
2
2
1
1
25
PART #
Y4400A
Y4405A
VO-350
Y4110A
VT25-28SS500
VT25-28SS250
VM4124
VB437TO
Y4155
VFSP2M-SS
VP312X1.00
Y4130
VO-245
Y4220
Y4210A
Y4320
Y4310A
Y4240
VT25-20BH375
VB437TO
VT50-20SS375
Y4230
VT31-18SH500
V2120-TORLON
Y4120
Y4162
VB.312TO
VT37-24SS312
Y4141
Y4160
X225
Y4150
X220
VM4250
VW97X595-048
VR4295
VR4220
Y4164
A1512
VW812X406-65
X281
A1513
VT37-16BH1.5
Y4175
Y4182
Y4159
VW1.0X759-04
Y4182
Y4159
VW1.0X759-04
VT37-34SS250
VO-244
VO-236
Y4435
Y4436
VW360X200-04
VT10-24SH1.2
Y4437
A1559
AY342-WHT
LIY-200 May 24, 2011 Rev10
