6.3 MONSOON MONITOR FRICTION LOSS

0
20
16
MONSOON MONITOR FRICTION LOSS
12
8
4
0
0

6.4 STREAM STRAIGHTENERS

6.4.1 STREAM STRAIGHTENERS WITH STACKED TIPS

Turbulence though
Monsoon Monitor is very low
but stream quality and reach
can be improved with the use of
the integral stream straightener
on the TFT stacked tip nozzle
(YST-4NN). See fi gure 6.4 for
the stacked tip's integral stream
straightener friction loss.
0
20
16
TFT STACKED TIP INTEGRAL STREAM
STRAIGHTENER FRICTION LOSS
12
8
4
0
0

6.4.2 STREAM STRAIGHTENERS WITH FOG NOZZLES

When using a fog nozzle it is
recommended that no stream
straightener be used since the
fog nozzle's fl ow path generally
serves as a stream straightener.
Use of a stream straightener
with a fog nozzle will increase
the stresses on the monitor's
gear train and may lead to
premature wear.
©Copyright Task Force Tips, Inc. 2004-2011
1000 2000 3000
4 PSI AT 1000 GPM
500
Monsoon Monitor Friction Loss
the
1000 2000 3000
3 PSI AT 1000 GPM
500
TFT Stack Tip Integral Stream Straightener Friction Loss
(LPM)
4000 5000 6000
15 PSI AT 2000 GPM
1000 1500
Flow (GPM)
Fig 6.3
(LPM)
4000 5000 6000
13 PSI AT 2000 GPM
1000 1500
Flow (GPM)
Fig 6.4
21
7000
1.2
1.0
0.8
0.6
0.4
0.2
0.0
2000
OK
7000
1.2
1.0
0.8
0.6
0.4
0.2
0.0
2000
NOT OK
LIY-200 May 24, 2011 Rev10
