5.4 RECOMMENDED PARK POSITION

For truck mounted applications it is recommended that the monitor
be parked in a position such that the monitor's nozzle rests against
a bracket or support surface. If a support surface is not available,
run the elevation against one of its travel stops to take some of
the backlash out of the gear drive. This will minimize bouncing of
the nozzle when the apparatus is traveling. Always be sure the
monitor is properly parked before moving the truck and know the
overall height to avoid damage from overhead obstructions such
as doors or bridges.

5.5 OVERRIDE KNOBS

In the event of electrical system failure on the monitor or fi re truck
the Monsoon Monitor is factory supplied with knobs so the monitor
may be manually operated. To make the Monsoon RC more
compact the manual override knobs may be removed. The drive
shafts have a hex so an 11/16" wrench or socket may be used for
manual override. Each drive shaft also has a secondary hex at
mid shaft so the shaft may be shortened by cutting and still have a
wrenching hex. The wrenching hexes are shown in fi gure 5.5.

6.0 FLOWS AND PRESSURES

6.1 STACKED TIPS FLOW AND REACH

Integral Stream
Straightener
50
Nozzle
Diameter Flow
(inches) GPM
2 840
2.25 1060
2.5 1310
2.75 1590
3.5
Nozzle
Diameter Flow
(MM) l/min
50 3180
57 4010
64 4960
70 6020
©Copyright Task Force Tips, Inc. 2004-2011
2-3/4" 2-1/2"
Stacked Tip Model YST-4NN
Nozzle Pressure (PSI)
60
Reaction Flow Reaction Flow
lbf GPM lbf
310 920 380
400 1170 480
490 1440 590
590 1740 710
Nozzle Pressure (BAR)
4.1
Reaction Flow Reaction Flow
kg l/min kg
140 3480 170
180 4430 220
220 5450 270
270 6590 320
11/16" (18 MM) Hex
Cut here to
shorten shaft
2-1/4" 2"
Fig 6.1A
80
Reaction Flow Reaction
GPM lbf GPM
1060 500 1190
1350 640 1500
1660 790 1860
2010 950 -----
5.5
Reaction Flow Reaction
l/min kg l/min
4010 230 4500
5110 290 5680
6280 360 7040
7610 430 -----
Fig 6.1B
Stacked Tip Flow Table
18
Fig 5.5
Wrenching Hexes on Drive Shaft
Protective Cap
Remove cap and install
smaller tips if desired.
Such as Model #MST-4NJ
(1-3/8", 1-1/2", 1-3/4", 2")
100
lbf
14.5 psi
630
1 gpm = 3.785 l/min
790
980
-----
7
kg
290
360
450
-----
Cut here to
shorten shaft
= 1 bar
LIY-200 May 24, 2011 Rev10
