Assembly Instructions
7
For disassembly, reverse steps 1-6.
Release the jib retaining strap and rotate jib
assembly outwards
Adjusting the Radius
5
Ensure the radius adjustment pin is fully engaged before use.
The operator can choose the most suitable radius
for use, by inserting the pin in the adjustment
plate
6
The decal specifies the reach values with
the upper value stating the outer shackle
position and the lower value stating the
inner shackle position
