Summary of Contents for ETC Foundation Rigging Controller
- Page 1 Product Information Guide Revision A C o p y r i g h t © 2 0 1 2 E le c tr o n i c T h e a t r e C o n t r o l s , I n c . A l l R i g h t s r e s e r v e d .
- Page 2 E T C pe r m i t s t h e r e p r o d u c t i o n o f m a t e r i a l s i n th i s m a n u a l o n l y f o r n o n - c o m m e r c i a l p u rp o s e s . A l l o t h e r r i g h ts a r e r e s e r v e d b y E T C .
-
Page 3: Table Of Contents
Document Conventions ....... .1 Help From ETC Technical Services ......2 Identifying the Software Version . -
Page 4: Introduction
PDF (such as word find, bookmarks, and commenting tools) ETC documents include the ability to click headings in the Table of Contents or Index and jump to the desired page. Also, our cross-references (indicated in blue italics like this: Operation, page 5) are links that may be clicked to jump to the specific part of the manual. -
Page 5: Help From Etc Technical Services
The software version can also be found after login in the main menu. Step 1: Push the menu button (ETC logo) found in the lower left corner of the LCD screen. Step 2: Choose SETTINGS from the pop up menu. -
Page 6: Responsible Use Of Rigging Equipment
W A R N I N G : ETC Prodigy hoists must only be used to move a maximum load equal to or less than the capacity of your specific hoist. Overloading the hoist may result in damage to the system, other property damage, serious injury, or death. -
Page 7: Working Load Limit (Wll)
Perform regular inspection and maintenance per the instruction manual. • The system must be inspected annually by a qualified ETC Rigging inspector. W o r k i n g L o a d L i m i t ( W L L ) The Working Load Limit (WLL) of any hoist is the maximum load capacity that a user may apply to a hoist or hoist system. -
Page 8: Operation
Operation O v e r v i e w The Foundation Rigging Controller is the primary control component of your ETC Rigging system. LCD touch screen Emergency stop Power button Joy stick port Go buttons Rotating locking barrel Foundation Product Information Guide... -
Page 9: Powering Up The Console
Powering Up the Console The bottom portion of the Foundation console rotates and locks for security. Keyed lock Step 1: If your console is in the closed and locked position, insert the key and unlock it. Step 2: Rotate the barrel towards you to reveal the button and joystick panel. Step 3: The power button can be found on the top left corner of the panel. -
Page 10: Accessing Help
Once you are logged in you will have access to the help system. To access the Foundation help system: Step 1: Press the Menu button (ETC logo) found in the lower left corner of the LCD screen. Step 2: Choose HELP from the pop up menu. - Page 11 Operation...
- Page 12 Service: (Americas) service@etcconnect.com (UK) service@etceurope.com (DE) techserv-hoki@etcconnect.com (Asia) service@etcasia.com Web: www.etcconnect.com Copyright © 2012 ETC. All Rights Reserved. Product information and specifications subject to change. 8060M2300 Rev A Released 2012-08 ...
