Start Indefinite Hold
This is an override function allowing a manual hold of all scheduled events. It is possible to select "End
Hold" to restore the scheduled programmed event. See
File Operations
The "File Operations" menu provides tools to save and load a
configuration file, update firmware, and restore factory defaults.
Operations from this menu provide operations for saving and
loading of files using removable USB media.
Save Configuration
Saving a panel configuration creates a file for storage to the root directory of a connected USB storage
device.
1:
Insert a USB storage device in the USB port on the front-left side of the Power Control Processor
user interface. The USB device must be compatible with the Power Control Processor. See
Compatible USB Storage Device
2:
Press [Enter] ( ) to access the main menu.
3:
Scroll to "File Operations" and press [Enter] ( ) to select. The "File Operations" menu displays.
4:
Use the [Up]
5:
Press [Enter] ( ). The "Save Configuration" screen displays and the default "Filename: Echo1"
is selected. You can save your file under a name between Echo1 and Echo16.
6:
To select a different filename, press [Enter] ( ). The selection will focus on "Echo#".
7:
Use the [Up]
selection.
8:
Scroll to "Save to USB key" and press [Enter] (
file will always be saved to the root directory of the USB device.
Load Configuration
Loading a panel configuration file replaces all existing configuration data (circuit assignment, presets,
sequences, and patching) with the new configuration. Before loading a new configuration onto the
Power Control Processor, it is recommended that you save the existing configuration file. See
Configuration
1:
Insert a USB storage device in the USB port on the front left side of the Power Control Processor
user interface. The USB device must be compatible with the Power Control Processor. See
Compatible USB Storage Device
2:
Press [Enter] ( ) to access the main menu.
3:
Scroll to "File Operations" and press [Enter] ( ) to select. The "File Operations" menu displays.
4:
Use the [Up]
5:
Press [Enter] ( ) to select "Load from USB Key".
6:
Use the [Up]
are named "Echo#.CFG" (the # could be any number from 1–16).You can descend into other
directories on the USB by scrolling to the name of the directory and pressing [Enter] ( ). You can
return from directories by selecting the ".." entry in a subdirectory location.
7:
When the configuration file to be loaded is selected, press [Enter] ( ). The dialog will display
"Loading Configuration".
Menu and Configuration
or [Down]
buttons to scroll to and select "Save Configuration".
or [Down]
buttons to scroll through the list, and press [Enter] ( ) to make the
page 35
on
.
or [Down]
buttons to scroll to and select "Load Configuration".
or [Down]
buttons to scroll through the USB directories. Configuration files
Holds
page 14
on
for information.
). The dialog will display "Saving to USB". The
page 14
on
for information.
page 27
on
.
File Operations
Save Configuration
Load Configuration
Update Firmware
Restore Defaults
Save
35
