Setting Up a Loaner Echo Architectural Control Processor (E-ACP)
Thank you for taking advantage of ETC's loaner program. The steps below will guide you through setting up your new
loaner and prepping your unit to ship for repair. If you run into any issues while following the setup process,
please
contact ETC Technical Services
by) until we can resolve the issue.
E-ACPs require an architectural configuration to function. If the steps below are not
followed, your loaner will not function correctly.
Ensure that power to the rack is disconnected before removing any components. Failure to
do so can result in damage to your equipment or personal injury.
Saving the Configuration
If your E-ACP is still operable, you will need to save its configuration to a USB drive or SD card.
If your E-ACP will not boot or is otherwise inoperable, skip to "Removing the Processor". You will need to rewrite this
configuration from scratch by following the "Re-Recording Presets" procedure at the end of the article.
To save your processor's configuration, insert a USB drive or SD card into the corresponding slot on the processor's
front panel.
Press [✓] to enter the Main Menu. Scroll down to [File Operations] and press [✓].
Press [✓] to select [Save Rack Config]. Select [Save to USB Media] or [Save to SD Media] and press [✓]. When the
config has been written to the removable drive, remove the drive from the processor.
https://support.etcconnect.com/ETC/Architectural/Echo/Echo_Architectural_Control_Processor_(E-ACP)/Setting_Up_a_Loan...
and hold off on sending your unit in (providing it's still functional enough to get
Updated: Fri, 21 Feb 2025 00:46:00 GMT
Powered by
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ETC E-ACP
Summary of Contents for ETC E-ACP
- Page 1 If your E-ACP is still operable, you will need to save its configuration to a USB drive or SD card. If your E-ACP will not boot or is otherwise inoperable, skip to "Removing the Processor". You will need to rewrite this configuration from scratch by following the "Re-Recording Presets"...
- Page 2 Once the config is loaded, exit the menu with by pressing [<]. The display should now read "System OK". Test system functionality and ensure you have control over the rack. If errors are present or the rack does not respond to control, contact ETC Technical Services. Quick Rack Setup If the loaner was unable to retrieve a dimming configuration from the rack, you may need to perform a quick rack setup to write a new dimming configuration from scratch.
- Page 3 [Record] and press [✓]. This will record the currently set levels as the selected preset. Press the lightbulb button again to enter the Dimming Control menu, then scroll down to [Release Set Levels] and https://support.etcconnect.com/ETC/Architectural/Echo/Echo_Architectural_Control_Processor_(E-ACP)/Setting_Up_a_Loan… Updated: Fri, 21 Feb 2025 00:46:00 GMT...
- Page 4 Please send only the items on the repair order; unless instructed otherwise, do not send in any accessories, cables, or peripherals. If you do not have the appropriate packing material, contact ETC Technical Services. Please ship to: ETC, Inc ATTN: RMA# <your RMA number>...
