• Power On Behavior: Determine the behavior for the control when the Power Control Processor
powers on. Options include "Last-Look" and "Off". The default is "Last-Look".
- Last-Look: Relays remain in their positions from the last power cycle, when the controller was
powered up, if there is no control source.
- Off: Relays go to Off when the controller is powered up, if there is no active control source for
DMX or sACN.
Preferences
• Backlight Mode: The backlight has three possible modes of
operation including Auto, On, or Off. The default is Auto.
- Auto: Keeps the display backlight illuminated after boot-
up and after last button push for a specified amount of
time.
- On: Keeps the display backlight illuminated at all times.
- Off: Turns off the backlight illumination.
• Backlight Time: Controls the length of time before the backlight turns off when in Auto mode.
The default is 3 minutes; it can be set from 0:10 sec to 9:59 min.
• Contrast: Contrast settings can be set from 1–100 from this screen or the home screen.
• Language: Default setting is English.
Network Settings
Network Setup provides editing and setup related to the Ethernet Interface card including IP address
configuration, sACN universe setup, and web UI enable and disable.
I P A d d r e s s
IP Address allows editing and setup of the network properties of
the Ethernet Interface card. Two options are available (Automatic
and Manual). Default is Automatic.
• Automatic: The Ethernet Interface option will attempt to
acquire an address from an Address (DHCP) server on the
network. If a DHCP server is not found, the card will default
to a Link Local address for the current power cycle.
• Manual: manual entry of an IP address, Subnet Mask, and Gateway are allowed. The default IP
and Gateway addresses will be 10.101.1.1. The default Subnet Mask will be 255.255.0.0.
s AC N U n i v e r s e s
Allows configuration of the sACN universes that are available for
patching. The Ethernet Interface card supports up to four sACN
universes.
Each universe must be set to a valid sACN universe number
between 1 and 63999 or zero (entered as 0, but shown as –), to
indicate that universe is unused.
When a value is changed, any output currently set to that
universe will be reconfigured to the new universe.
W e b I n t e r fa c e
"On" enables the web UI and "Off" disables the web UI. When the web UI is disabled, it can only be
enabled from the Power Control Processor user interface. See
CAUTION:
26
Setting Web Interface to "Off" will disable the ability to remotely configure
the device from Net3 Concert.
Preferences
