14 | Check list for the installation of the Webasto charging station

14 Check list for the installation of the Webasto charging station
Charging station
Charging power
Serial number
Material number
General :
Installation, electrical connection and initial operation of the charging station must be carried out by an electrician.
Local conditions:
The charging station has not been installed in an explosion sensitive area (EXzone).
The charging station has been installed in a location where falling objects cannot damage the charging station.
The charging station should not be exposed to direct rain or sunlight in order to prevent damage.
The location of the charging station should be selected such that vehicles cannot inadvertently collide with it.
The legal requirements for electrical installations, fire protection, safety regulations and escape routes have been met.
The charging cable does not block any passageways.
The charging cable and coupling has been protected against coming into contact with external heat sources, water, dirt
and chemicals.
The charging cable and coupling has been protected against being driven over, trapped or any other mechanical haz-
ards.
The customer/user was informed how the Webasto Pure voltage is switched off with the installation-side protective
devices.
Charging station requirements:
The cable support sleeves for the power cable and data cable (for live only) have been fitted during installation.
The kink protection for the charging cable has been screwed onto the charging station and the rubber seal has been fit-
ted correctly into the kink protection.
The suitable charging cable (11 kW or 22 kW) has been installed in the charging station (as per type label) during install-
ation. The cable clamp that ensures the charging cable has strain relief has been fitted. The specified torques have been
observed. The charging cable has been connected as per the instructions in the operating instructions.
Tools and installation remnants have been removed from the charging station before closing the cover.
The serial number of the charging station has been registered on the online portal: https://webasto-charging.com
Customer/client:
Place:
Date:
Electrician/contractor:
Place:
Date:
