CCR2+ Controller
1.
Product description
2.
Technical data
1)
To select proper power transformer
please follow formula: 24 V 10VA
(controller) + 7 VA*/per each actuator
3.
Installation
8 | © Danfoss | 2019.02
The CCR2+ is a control used for optimizing
the thermal disinfection process in hot water
systems with functions such as temperature
registration and monitoring circulation hot water
systems. The control is connected to thermo
Temperature sensor (S0, S1-S20 / S21-36)
Temperature range (registration)
Measuring accuracy
Inputs: B1, B2 and B3
Number of control valves (risers)
Output signal to actuators
Alarm signal output
Relay output
Type of memory
Capacity of memory
Timer: Real time clock
Communication interfaces
Default IP settings
Ambient temperature
Transport temperature
IP rating
Power supply
Power consumption (Master controller only)
Power consumption (Slave Unit only)
Weight
Installation
For easy access, the CCR2+ controllers should
be installed in electrical enclosure on DIN rail 35
mm. Enclosure with DIN rail should be mounted
onto the wall (sub - station or boiler room) as
close as possible to the heat source. DIN rail and
enclosure are not included.
actuators type TWA-A and remote temperature
sensors PT1000, type ESMB, installed on each
thermostatic circulation valve, type MTCV
(Multifunctional Thermostatic Circulation Valve).
Pt1000, S0- type ESMC / ESM11, S1 ... S36 – type ESMB
–20 °C ... +120 °C
± 0,1 K
Free contact (5 V 1 mA)
20, additional 16 with system extension via CCR+ Slave Unit
24 VDC max. 1 A
24 VDC max. 1 A
0 ... 24 DC max. 1 A
Build-In
8 GB
Built-in battery - service life 10 years
- Wi-Fi (communication port only)
- TPC/IP port (LAN cable connection)
- Modbus RS485 RTU
- IP Modbus (LAN cable connection)
- Default LAN IP address (static): 192.168.1.100
- Default WiFi access IP address (static): 192.168.1.10
- IP address mask: 255.255.255.0
- Gateway address: 192.168.1.1
- DNS address: 192.168.1.1
- CCR name: ccrplus
- default password: admin1234
0 ... 50 °C
–10 ... +60 °C
IP 20,
24 VDC
1)
10 VA
1)
3 VA
0.3 kg
DIN rail 35 mm
It is recommended to install the standard 24
VDC transformer in the same box as CCR2+
(not supply). The transformer power depends
on numbers of actuators (number of risers in
heating installation). To select proper power
transformer please follow formula: 24 V 10VA
(controller) + 7 VA*/per each actuator
Example (building with 20 risers):
10VA (for controller) + 7VA x 20 actuators = 150VA
VI.D3.C2.02
