Scheduler Menu; Tests Menu; Network Menu - Danfoss CCR2+ Operating Manual

CCR2+ Controller
10. CCR2+ DASHBOARD
(Web App Screen)
(continuous)
14 | © Danfoss | 2019.02

SCHEDULER MENU:

No. Name Description
1. Sunday Disinfection schedule for selected (Active/non Active) day of the week. To be used in B1+SCH,
2. Monday S0+SCH mode.
3. Tuesday
Active: Disinfection is permitted in selected time periods
59 4. Wednesday
5. Thursday non Active: Schedule is not active
6. Friday Start time (hh:mm): set start time period of disinfection
7. Saturday Stop time (hh:mm): set finishing time period of disinfection
Set Settings Click »Set Settings« to confirm changes
Load settings 1 Load settings from memory 1
Load settings 2 Load settings from memory 2
Save settings 1 Save settings into memory 1
Save settings 2 Save settings into memory 2

TESTS MENU:

No. Name Description
Open: Selected output contact is open
Close: Selected output is closed to common (C)
60 O1...O4
Auto
Factory setting: Auto
Open: selected valve is closed
Close: selected valve is open, shortcuted to common (C)
61 V1, ..., V36 Auto OnOff: selected valve works in On/off mode
AutoPWM: selected valve works in PWM mode
Factory setting: AutoPWM
Save settings Click »Save Settings« to confirm changes
Set all as Open All Open
Set all as Close All Close
Set all as Auto OnOff All Auto On/Off
Set all as AutoPWM All Auto PWM
DATA MENU:
No. Name Description
62 Delete all logs Erasing of log file
63 GO to By selecting time period, log files will be shown and ready for download (*.CSV)

NETWORK MENU:

No. Name Description
Enable – Modbus is switch on
64 Modbus
Disable – Modbus is switched off
Type of date transmission:
ModBus 96 (9.600)
Mod Bus 19 (19.000)
65 Modbus baudrate
ModBus 38 (38.400)
FBus
Factory setting: ModBus 96
None (transmition parity disabled)
Even (»Even« type of transmition parity enabled)
66 Modbus parity
Odd (»Odd« type of transmition parity enabled)
Factory setting: Odd
Unit Address for Mobus RTU RS485
67 Modbus address
Factory setting: 1
The IP address that the router assigned to this device when it joined the network. This number can
68 LAN IP address change if a device is disconnected and rejoins the network
Factory setting: 192.168.1.100
Identify network address of an IP address
69 LAN IP address mask
Factory setting: 255.255.255.0
The gateway address (or default gateway) is a router interface connected to the local network that
LAN Gateway
70 sends packets out of the local network
address
Factory setting: 192.168.1.1
Name of CCR2+ (relevant for network search)
LAN name (min. 2 Please note that after changing this value, local network dns server need to be refreshed. This
71
char., max. 15 char.) process is depend on current network configuration and can take up to few hours.
Factory setting: ccrplus
Dynamic Host Configuration Protocol
Disable
72 LAN DHCP
Enable
Factory setting: disabled
LAN connected
73 Number of LAN connected clients to CCR2+
clients
WIFI name (min. 2 Wi-Fi name (can be changed)
74
char., max. 15 char.) Factory setting: ccrwifi
WIFI pass (min. 8 Password name (can be changed)
75
Factory setting: admin1234
char., max. 15 char.)
WIFI connected
76 Shows IP and name of Wi-Fi connected device
client
Change Login Password name for access to CCR2+ App
77
password: Factory setting: admin1234
VI.D3.C2.02
