A – Specifications
Appendix A – Specifications
Duality Fuse Console
Parameter Condition
Height To top of meter trim
Height adjustment
Width: 24 channel console
(1) 48 channel console
48 channel console plus patch
72 channel console
96 channel console
19" racking section
Producer's table section
Depth
Weight: 24ch
48ch
72ch
96ch
19" racking section
1U patchrow
Producer's section
Heat dissipation: 24ch
48ch
72ch
96ch
Voltage Input range
Current: Over voltage range: for 1st 24ch
For additional 24 channel bays
Power factor
Fusing None
Noise Fanless
Connectors: Mains input
MIDI
Network
Line level audio
Microphone input
Mini LS output
TB / Listen Mic / FB sends
USB
Serial
1. Dimensions apply to straight consoles only. For dimensions of ProStation consoles and custom consoles which include
corner sections please contact to SSL's Project Engineering Department.
Page 50
Value Unit
982 mm
-0 +10 mm
1,710 mm
2,700 mm
3,190 mm
3,690 mm
4,680 mm
488 mm
603 mm
1,024 mm
190 Kg
310 Kg
430 Kg
550 Kg
15 Kg
3.2 Kg
18 Kg
1,005 W
1,565 W
2,225 W
2,885 W
100 – 240 V
9.1 – 3.9 A
6.9 – 2.9 A
0.95
IEC male
5-pin DIN 180° female
RJ45 100BaseT
25-way D-type female
XLR 3-pin female
XLR 3-pin male
1/4" TRS jack female
4-pin type A
9-way D-type female
projeng@solidstatelogic.com
Duality Fuse Installation & Setup Guide
Appendices
Notes
No patchbay
No patchbay
Internal patchbay
No patchbay
No patchbay
Empty
Each
±10%
24 channels inc centre section
1 for 48ch, 2 for 72ch, 3 for 96ch
