ETC Releve Spot Installation Manual

ETC Installation Guide
Relevé Spot

Introduction

Congratulations on your purchase of the Relevé Spot automated
luminaire from ETC.
Relevé Spot is an LED-based automated luminaire that provides high-
quality color control, predictable smooth pan and tilt control, and
unparalleled zoom optics.
Relevé Spot builds on the legendary color control of ETC LED products
and provides a reliable, full-featured automated luminaire of the highest
quality.

Safety Notices

Relevé Spot is a high-performance automated spot luminaire that is
intended for professional use only . Read the entire user manual before
installing and operating this equipment. The user manual is available as
a download from the ETC website etcconnect.com.
READ AND FOLLOW THESE SAFETY WARNINGS BEFORE USE:
For indoor use only. The luminaire is IP20 rated for installation in dry locations only. When
•
selecting the installation location, ensure the luminaire will not be exposed to extreme cold or
heat outside of the operational range (see
Do not project the light beam onto combustible surfaces or materials. The minimum distance
•
you should maintain from the luminaire head to an illuminated surface is 2 m, and the minimum
distance from the luminaire head to any flammable materials (decorations, etc.) is 0.1 m.
Disconnect the luminaire from power and DMX and allow it to cool before performing any
•
cleaning and maintenance procedures.

Warranty Service

ETC warranty terms and conditions are available on the ETC website etcconnect.com.

Installation

Unpacking Instructions

The luminaire is fully calibrated and tested at ETC, then carefully packaged in a shipping carton that
includes the luminaire and two clamp mounting rails.
Visually inspect the shipping carton for damage that may have occurred during transit. If the shipping
carton shows signs of damage, document the damage fully before unpacking the luminaire.
Documentation of any damage is helpful when reporting a claim with the carrier.
The luminaire weighs approximately 67 lbs. (30.4 kg). For your safety, ETC recommends that two
people unpack the luminaire from the shipping carton. Use the provided handles on the yoke arms
and the enclosure to lift the luminaire from the shipping carton.
The shipping carton and packaging materials can be valuable if you ever need to ship the fixture,
including transporting the fixture for service. Do not discard. If you do not require this packaging for
future use, please recycle the materials through your local recycling program.
