- Page 1 Steelcase, Inc. Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 42-DH-DA & 32-DH-DA Desk High Return Units Tools 5/16” SOCKET 3/16” DRILL BIT Assembly Directions Printed In U.S.A. 93-9500971 A Page 1 of 5...
- Page 2 Channel spacers (used on 4200 only) Notes The following assembly steps apply to either a right hand or left hand 42-DH-DA or 32-DH-DA unit. A left hand unit is shown for all instructions. A steel top has been shown. When assembling a wood top , the same instructions apply.
- Page 3 Attaching back panel Fasten back panel to top with (3) #10 x 1/2 sheetmetal screws. Before tightening screws, be sure to have a 3/32” overhang between the back panel and end of top. END PANEL 4200 ONLY “Z” BRACKET REVEAL BACK PANEL #10 x 1/2”...
- Page 4 Installation of bottom panel plate, NOTE: See figure “a”, page 3for correct plate Attach bottom panel plate to pre-drilled holes in end panel (2) #10 x 1/2” sheetmetal screws. Attach plate to back panel using (2) #10-24 x 3/8” machine screw and hex nuts. #10-24 x 3/8”...
- Page 5 Insert (2) angle clips into hanger bracket. Then insert (2) 1/4-20 machine screws. Do not tighten at this time. Place open end of return unit top on hanger bracket, checking for proper alignment. Mark holes. Remove return unit and drill (3) 5/32” dia.
