Steelcase 3200 Series Assembly Directions
Attaching an extension top to a desk
Hide thumbs
Also See for 3200 Series:
- Installation instructions manual (11 pages) ,
- Assembly directions (6 pages)
Related Manuals for Steelcase 3200 Series
Summary of Contents for Steelcase 3200 Series
- Page 1 Steelcase, Inc. Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Attaching An Extension Top To A 3200, 3300 or 4200 Series Desk EXTENSION TOP Tools 3/8” SOCKET 5/32” DRILL BIT Assembly Directions Printed In U.S.A. 93-9500642 - Page 1 of 2...
- Page 2 Align braces with extension top using a square. Secure both braces to the extension top with No. 10 x 1/2 screws provided. EXTENSION TOP Align extension top with end of desk top. Mark and drill 5/32” holes in desk top edge. PRE-DRILLED Attach spacer plates to extension top by removing HOLES...
