Product Ratings - Linak Desk Frame 1 Assembly Manual

PACKING LIST
Inner Rail x 1
Foot x 2
Desk Switch
Motor
Cable x 2

PRODUCT RATINGS

Weight limit for two-leg DL5/6 desk: 1600N (363 lbs
including weight of the desk top.
Kick & Click Fixed Frame: Fits desks with 47.25"+ tops.
(Actual frame width of 44.9")
Kick & Click Large Adjustable Frame: Fits desks from 54" to
84" (actual frame width of 52.75" to 76.3").
Kick & Click Short Adjustable Frame: Fits desks from 41" to
60" (actual frame width of 38.25" to 50").
Outer Rail x 1
Leveler for
Foot x 4
Mains Cable x 1
Cantilever x 2
Desk Leg x 2
8-15 x 0.75"
Tapping
Screw x 13-20
Application of the DESKLINE
Irrespective of the load the duty cycle 10% ~ 2
minutes of continuous use at full load, followed
by 18 minutes of pause stated in the data sheets, must
NOT be exceeded as this will result in super heating of the
motor, the brake and the spindle nut. Exceeding the duty
cycle will result in a dramatic reduction of the life of the
system.
This product is inteded for indoor use only.
Kick Lock x 2
Clamp x 2
Control Box x 1
10-12 x 2"
Tapping M6 x 16 mm
Screw x 2
Allen Bolt x 8
DL5/6 system:
®
7
