10.
Installing desk switch.
10.1
: Attach the desk switch to the table top.
Align desk switch with the edge of the table top.
Pre-drill holes for screwing desk switch to top.Screw in
desk switch, being careful not to over tighten screws.
10.2
: Plug the desk switch into the control box. This switch can be plugged into either port
"A1" or "A2".
11.
Flipping Your Desk Over
WARNING! 2 PERSON LIFT TO AVOID INJURY
AND DAMAGE TO THE PRODUCT
The desk switch sticks out the front edge of the desk,
and can be damaged while flipping the desk over. Do
NOT flip the desk in a way that could damage the desk
switch. (or remove desk switch before flipping the desk).
14
DO NOT OVER
TIGHTEN SCREWS
