Linak Desk Frame 1 Assembly Manual page 21

Symptom
Desk is uneven
P5 – Check for faulty component WITHOUT error codes (no digital display on desk switch, no Bluetooth)
Symptom
System will move down but
not up
System will not initialize.
OR
System won't complete the full
range of motion.
– After each of these steps,
attempt to initialize (P1).
Procedure
1. Initialize the desk. If both legs begin to run down, complete the initialization. If only
one leg moves, stop and move to Step 2.
2. Check motor cable connections. Check to ensure motor cables are not pulled during
movement. With a standard, Plug & Play control box, it's possible that only one leg
is connected, and connected to Channel 1. In this case, it will initialize and run
Channel 1 only. If there is only one leg but it's connected to Channel 2, it will not
initialize.
3. If a motor cable was disconnected, try initializing again.
4. If unsuccessful, connect the desk leg from Channel 2 into Channel 1, with nothing in
Channel 2, and initialize.
5. Try initializing the same leg that's in Channel 1, but with a different motor cable. If it
still won't initialize, replace the desk leg.
Procedure
1. Initialize (P1)
1. Check mains cable connection. Test power outlet using another device (lamp,
phone charger, etc.)
2. Plug in a new switch.
3. Connect all existing cables to a new control box.
4. Try pressing and releasing the down button a few times before pressing and
holding for 5 seconds.
21
