- Page 1 © 2010 by Huchez Treuils S.A.S. Winches Mini electric winch PALANBOX 80, 160 and 230 kg Instructions manual ________________________ 3.362.11-3...
-
Page 2: Table Of Contents
2008 by Huchez Treuils S.A.S. In order to ensure the improvement of its products, HUCHEZ reserves the right to modify the materials as described below and to provide them, in this case, other than described in the illustrations in this manual. -
Page 3: Safety Instructions
© 2008 by Huchez Treuils S.A.S. consult the manufacturer regarding use in extreme conditions. Warning! If the ambient temperature is below 0°C, the brake must be tested to ensure that it does not present a malfunction due to frost. -
Page 4: Warranty
© 2008 by Huchez Treuils S.A.S. by some other means. Make sure that no person or object is in front of or behind the moving load. Secure or hook the load or the PALANBOX in a stable manner. If necessary, take the necessary ... -
Page 5: Receipt Of Material
© 2008 by Huchez Treuils S.A.S. spare parts from the original manufacturer. During the warranty period, the seller must replace or repair parts that are recognised as defective after an inspection by their certified and authorised service, free of charge. -
Page 6: Equipment Presentation
© 2008 by Huchez Treuils S.A.S. Suitability examination (article 5-1): appropriate equipment and compliant installation. Must be provided, in writing, by the user (article 3d). Assembly and installation examination (article 5-11): equipment installed according to the instructions. Operational examination (article 6c or 14-II): under load with safety tests. -
Page 7: Handling - Storage - Transport
© 2008 by Huchez Treuils S.A.S. 6.2. Dimensions 6.3. Specifications: Model: PALANBOX 80 PALANBOX 160 PALANBOX 230 Frequency 50 Hz 50 Hz 50 Hz Nominal load 80 kg 160 kg 230 kg Speed 30 m/min 22 m/min 14 m/min Lifting height... -
Page 8: Assembly - Commissioning - Operation
© 2008 by Huchez Treuils S.A.S. 8 - Assembly - Commissioning - Operation 8.1. Fastening the winch As the winch is designed for suspension mounting, mount it on a strong and stable bar or on the optional jib crane. Once suspended, make sure that the winch body or the load is not obstructed by a structural component or other obstacle. - Page 9 © 2008 by Huchez Treuils S.A.S. 8.3. Fastening the work cable: 8.3.1 Onto the device: The cable must be lugged sleeved at each end. Pass the cable through the fork of the limit switch. After removing the cover screw, insert the end into the drum, through the hole provided for this purpose.
- Page 10 © 2008 by Huchez Treuils S.A.S. 8.6. Unwinding the cable When the cable is fully unwound, it changes position and goes from the O position to the X position. It is very dangerous to use it in this position. When the safety feature has stopped the movement, press the button ...
-
Page 11: Upkeep - Maintenance
© 2008 by Huchez Treuils S.A.S. Carbon brush Drain bolt holder screw 9 - Upkeep - Maintenance Regularly check that the device is level and that it is securely fastened. Also check the condition of the lifting device according to the specifications of its technical manual and in particular the chain, or the cable, the hook and the brake. - Page 12 © 2008 by Huchez Treuils S.A.S. Before blocking the brush, position the O-ring properly. A set of carbon brushes has two components. Make sure that these two components are placed simultaneously on both sides of the winch. Carbon brush length 9.4.
-
Page 13: Decommissioning
© 2008 by Huchez Treuils S.A.S. 10 – Decommissioning When the equipment is in a state of disrepair likely to cause danger, the user is obliged to ensure that this equipment is disposed of, namely by decommissioning or possibly dismantling. -
Page 14: Malfunctions
© 2008 by Huchez Treuils S.A.S. 12 – Malfunctions If you have followed the assembly and operating instructions, any incidents that may occur should be minor. The following tips will help you to troubleshoot issues quickly. When the winch does not start after several attempts, or if a faulty operation occurs, check the following:... -
Page 15: Annexes
© 2008 by Huchez Treuils S.A.S. IRREGULARITY POSSIBLE CAUSE WHAT TO DO? OBSERVED (result) (result) (result) The contact B has melted on the control box Replace the 3-button control box Burned out diode Replace the diode paying attention to the poles... -
Page 16: A - Optional Equipment
© 2008 by Huchez Treuils S.A.S. Optional equipment Jib crane: consult us. Offering a 180 ° rotation, this removable and light accessory is the essential complement for the PALANBOX, with its use on prop or scaffolding. Reach: 0.90 m Original manual... -
Page 17: B - Spare Parts
© 2008 by Huchez Treuils S.A.S. Spare parts PALANBOX 80 kg Original manual Reproduction prohibited... - Page 18 © 2008 by Huchez Treuils S.A.S. PALANBOX 80 kg N° piece Ref. Description Quantity Rear cover Reducer 880565 Ratchet stop 880506 reduction 881566 Brake 881567 reduction 880469 Reducer box 881568 Suspense 880471 Carbon brush holder 880472 Carbon brush 110~240 V...
- Page 19 © 2008 by Huchez Treuils S.A.S. PALANBOX 160 kg Original manual Reproduction prohibited...
- Page 20 © 2008 by Huchez Treuils S.A.S. PALANBOX 160 kg N° piece Ref. Description Quantity Rear cover Reducer 880493 Ratchet stop 880547 Brake 881497 reduction 881498 reduction 881499 reduction 880500 Reducer box 880470 Suspense 880476 Carbon brush holder 880472 Carbon brush 110~240 V...
- Page 21 © 2008 by Huchez Treuils S.A.S. PALANBOX 230 kg Original manual Reproduction prohibited...
- Page 22 © 2008 by Huchez Treuils S.A.S. PALANBOX 230 kg N° piece Ref. Description Quantity Rear cover Reducer 880493 Ratchet stop 880547 Brake 881507 reduction 881498 reduction 881508 reduction 880500 Reducer box 880470 Suspense 880476 Carbon brush holder 880472 Carbon brush 110~240 V...
-
Page 23: C -Electrical Diagram
© 2008 by Huchez Treuils S.A.S. –Electrical diagram POWER MOTOR SOCKET RECTIFIER RESISTOR D RESISTOR GROUND RESISTOR D LIMIT SWITCH BLACK BROWN BLUE GREY YELLOW SOCKET BLACK BROWN BLUE GREY YELLOW Emergency stop WHITE WHITE UPWARD BROWN DOWNWARD YELLOW BROWN... -
Page 24: D - Maintenance Log
© 2008 by Huchez Treuils S.A.S. D – Maintenance log The maintenance log for HUCHEZ hoisting winches can be downloaded from our website www.huchez.com under the heading “After-sales service”. Original manual Reproduction prohibited... - Page 25 © 2010 by Huchez Treuils S.A.S. Original manual Reproduction prohibited...
