Huchez TIREX 150 Kg Instruction Manual

Manual gear winches

Advertisement

Quick Links

©
2011 by Huchez Treuils S.A.S.
Manual gear winch
Manual winches
TIREX 150 and 300 Kg
UK
Instruction manual _________________________
129-236.11/5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIREX 150 Kg and is the answer not in the manual?

Questions and answers

Summary of Contents for Huchez TIREX 150 Kg

  • Page 1 © 2011 by Huchez Treuils S.A.S. Manual gear winch Manual winches TIREX 150 and 300 Kg Instruction manual _________________________ 129-236.11/5...
  • Page 2: Table Of Contents

    PRODUCT DEVELOPED AND MANUFACTURED ACCORDING TO EUROPEAN STANDARD EN 13157 - REGISTERED DESIGN To ensure the constant improvement of its products, HUCHEZ reserves the right to change the equipment as described below and, in this case, to supply products which differ from the illustrations in this instruction manual.
  • Page 3: General Warning

    © 2011 by Huchez Treuils S.A.S. 1 - General warning This machine is governed by European regulations and, more specifically, machinery directive 2006/42/EC and the European standard EN 13157. Before using this winch, the user must read this instruction manual and comply with all the ...
  • Page 4 © 2011 by Huchez Treuils S.A.S. 2.2. Dimensions: Possible rope release: Translation of the original instructions Reproduction prohibited...
  • Page 5: Handling - Storage

    © 2011 by Huchez Treuils S.A.S. 2.3. Technical specifications Capacity Capacity Number rope Max. Minimum Weight Model on 1 on the handle lift per turn (ropeless layer Kg last layers force Kg of the winch) Kg Ø Capacity layer Kg...
  • Page 6: Use, Assembly And Set Up

    © 2011 by Huchez Treuils S.A.S. 4 – Use, assembly and set up The following precautions should be respected. 4.1. Fastenings Fixing with four Ø 10 mm screws Use at least type 8.8 screws. 4.2. Rope Make sure the rope used is right for the application.
  • Page 7 © 2011 by Huchez Treuils S.A.S. Rope assembly: 1) Pass the rope through the drum until it protrudes at the rear of the winch. 2) Pass the rope through the first hole of the rope clamp. 3) Pass the rope through the second hole of the rope clamp until 2 cm of rope protrudes and tighten the screw (using a BTR no.
  • Page 8: Servicing And Maintenance

    © 2011 by Huchez Treuils S.A.S. 4.4. Disengaging Engaged Disengaged - Never disengage when the winch is loaded. In the event of mishandling, a device blocks the disengaging lever when a load is applied to the winch. - The winch is also provided with a security device that prevents the rope from being wound in the wrong direction.
  • Page 9: Contraindications For Use

    © 2011 by Huchez Treuils S.A.S. Automatic brake application: The brake will apply automatically when a winch is placed under a minimum load of : . 10 kg for the TIREX 150 . 15 Kg for the TIREX 300. 6 – Contraindications for use Before using the equipment, check for potential causes of overloading such as: adhesion to the ground, suction, jamming, etc.
  • Page 10: Precautions For Use

    © 2011 by Huchez Treuils S.A.S. 7 – Precautions for use Long descents are liable to overheat and damage the braking system. It is strongly advisable to wait  a few minutes half way (around 12 meters for the TIREX 150 and around 4 metres for the TIREX 300) through descent phases.
  • Page 11: Taking Out Of Use

    © 2011 by Huchez Treuils S.A.S. 9 – Taking out of use If the equipment is in a state of disrepair likely to give rise to risks, the user is obliged to ensure that this equipment is eliminated, i.e.: that it is taken out of service, and possibly: disassembled.
  • Page 12: Spare Parts

    © 2011 by Huchez Treuils S.A.S. 11 – Spare parts TIREX 150 Kg Part no. Description Part no. Description 2763 GFM-2023-21 bearing ring 23451 Structure 13162 10 x Hc M6 headless screw 23452 Drum 13659 18 x aluminium 3.2 rivet...
  • Page 13 © 2011 by Huchez Treuils S.A.S. TIREX 300 Kg Part no. Description Part no. Description 2763 GFM-2023-21 bearing ring 23451 Structure 13162 10 x Hc M6 headless screw 23452 Drum 13659 18 x aluminium 3.2 rivet 23453 Disengageable crown 13681...
  • Page 14: Example Of The Declaration Of Conformity

    © 2011 by Huchez Treuils S.A.S. 12 – Example of the Declaration of Conformity Translation of the original instructions Reproduction prohibited...

This manual is also suitable for:

Tirex 300 kg
