- Page 2 Installation manual of KTS-O-(E)S type fire dampers in building barrier 1488 SMAY Sp. z o. o. 1488-CPR-0445/W EN 15650:2010 Cut-off fire damper Type: KTS-O-E, KTS-O-S Nominal activation conditions/sensitivity: Closing/opening in appropriate moment and acceptable time - pass Response time/closing time – pass Operational reliability: KTS-O-E 10 000 cycles –...
- Page 3 2. Check whether the damper blade could be opened and closed (fully open and closed position). To open fire dampers KTS-O-E use the actuator key. The full opening and closing must proceed smoothly (not stepwise).
- Page 4 Installation manual of KTS-O-(E)S type fire dampers in building barrier Figure 1. Installation method of fire damper KTS in rigid barrier – wall page 4 z 9 Version: 3.1...
- Page 5 In such case, ventilation duct would be partially inbuilt in the fire barrier KWP built-in inside the barrier Figure 2. Diagram of the KTS-O-E(S) fire damper inbuilt in a barrier thicker than the length of the damper body page 5 z 9...
- Page 6 4. After drying of the mortar, remove used supports and suspensions which were used during installation of the fire damper. Variant II – Recommended by SMAY company 1. Make an opening in the ceiling with the minimal size DN+70 [mm] 2.
- Page 7 Installation manual of KTS-O-(E)S type fire dampers in building barrier Figure 3. Installation method of fire damper KTS in rigid barrier – ceiling page 7 z 9 Version: 3.1...
- Page 8 Installation manual of KTS-O-(E)S type fire dampers in building barrier Figure 4. Installation method of fire damper KTS in rigid barrier – ceiling page 8 z 9 Version: 3.1...
- Page 9 Installation manual of KTS-O-(E)S type fire dampers in building barrier Mounting plates pos. 1 may be made to size and provided by SMAY L.L.C. company or made by the customer in accordance with drawing and instruction. Figure 5. Mounting plate pos. 1 Detail –...
