  • Page 1 WKP-P Technical Rectangular fire damper Documentation https: www.smay.eu...
  • Page 2 Technical documentation WKP-P 2434 SMAY Sp. z o.o. CSWU:2434-CPR-0285 DWU:024-CPR-2017 PN-EN 12101:2012 Fire damper type: WKP-P Nominal activation conditions/sensitivity: Automatic starting Pass Closing/opening during the test at the right time Response time/Closure time: Automatic starting Pass 300 cycles <120s. – single Reliability: 10 000 cycles <120s.

  • Page 3: Table Of Contents

    Technical documentation WKP-P Version 6.2 SMAY reserves the right to make changes to this document. TABLE OF CONTENT INTRODUCTION ....................3 LEGAL REGULATIONS ..................3 INTENDED USE ....................3 TECHNICAL DESCRIPTION .................. 5 BELIMO ELECTRIC ACTUATORS USED IN WKP-P ............ 6 ACCESSORIES FOR WKP DAMPERS ..............

  • Page 4: Introduction

    – Part 2: Fire dampers, Part 10: Smoke control dampers.” The WKP-P-E-W fire dampers are classified as tightness class C (housing tightness) devices on the basis of tests carried out according to EN 1751 “Ventilation for buildings. Air terminal devices. Aerodynamic testing of dampers and valves.”...
  • Page 5 Technical documentation WKP-P WKP-P fire dampers are intended for installation on internal and external building partitions as also at a distance from them. In case of external wall installation, use of finishing element is required (intake or exhaust),which will protect from influence of atmospheric factors.

  • Page 6: Technical Description

    The mechanism is made up of, among other things, gears made of fire-rated materials, blades and an electric actuator. The permissible air velocity for the WKP-P-E damper in a B x H connection duct is 12 m/s. During normal operation of the system, blades can be in open or in closed position.

  • Page 7: Belimo Electric Actuators Used In Wkp-P

    Technical documentation WKP-P Table 2. WKP-P weight [kg] Width, B [mm] 1000 1100 1200 BELIMO ELECTRIC ACTUATORS USED IN WKP-P Actuator BEN series: BEN230,  BEN24,  BEN24-ST,  BEN24-SR.  where: ST - connection plug SR - analog control...
  • Page 8 Technical documentation WKP-P Wiring diagram BLE230 and BE230 Page 7 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 9 Technical documentation WKP-P Wiring diagram BLE24 and BE24 Page 8 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 10 Technical documentation WKP-P Wiring diagram BLE24-ST and BE24-ST Technical data: BEN230 BEN24 (-ST) Page 9 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 11 Technical documentation WKP-P Technical data: BEE230 BEE24 (-ST) Page 10 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 12 Technical documentation WKP-P Technical data: BE230 BE24 (-ST) Page 11 z 31 Version: 6.2 Date of editing: 29.03.2024 r.

  • Page 13: Accessories For Wkp Dampers

    WKP-P ACCESSORIES FOR WKP DAMPERS WKP-P dampers can be used as transfer dampers with use of KST type grilles with horizontal or vertical lamellas or with use of MKW flat or convex honeycomb mesh cover. Both products are used to prevent the damper from colliding with unwanted objects, covering sensitive moving parts.

  • Page 14: Conditions Of Transport And Storage

    Before installing the fire dampers, make sure that there are no damage, during transport or storage, that could block the baffle. Check that the baffle can be opened and closed (full opening and closing position). To open fire dampers WKP-p use the actuator key.

  • Page 15: Instalation Technology - Rigid Wall

    Rigid wall Figure 5. Dimensions of the installation opening of the WKP-P dampers in rigid wall with a horizontal and with vertical axis of rotation of the baffle. The C dimension is given in the table. H – nominal height of the damper Page 14 z 31 Version: 6.2...
  • Page 16 WKP-P Figure 6. Installing method of WKP-P fire dampers in rigid wall, baffle axis should be in line with wall axis Figure 7. Installing method of WKP-P fire dampers in rigid wall, baffle axis should be in line with wall axis Page 15 z 31 Version: 6.2...
  • Page 17 Technical documentation WKP-P Figure 8. Installing method of WKP-P fire dampers in rigid wall Page 16 z 31 Version: 6.2 Date of editing: 29.03.2024 r.

  • Page 18: Promaduct

    60 mm width. Connection of damper and the wall, and damper with the band must be made by K84 glue. The sides of the duct and the band must be connected by using 4,2x90 – 4,8x120 screws. Figure 8.Installing method of WKP-P fire dampers with PROMAT boards duct Page 17 z 31 Version: 6.2...

  • Page 19: Installation Technology - Structures Thicker Than 125 Mm

    INSTALLATION TECHNOLOGY – STRUCTURES THICKER THAN 125 mm In rigid walls, with thickness less than or equal to 125 mm, WKP-P fire dampers are installed in this way that an axis of the fire baffle matches the axis of the wall, and ensure a concentricity of fire damper and installation opening.

  • Page 20: Installation Technology - Flexible Wall With 125Mm Thickness

    After mounting the collar, remove the supports or suspensions, check the fire damper correct operation and leave it in open position. Figure 10. Installation method of fire dampers WKP-P in flexible wall with 125 mm thick Page 19 z 31 Version: 6.2...

  • Page 21: Installation Technology - Mkw Honeycomb Mesh Cover And Kst Grille

    Technical documentation WKP-P Figure 11. Installation method of fire dampers WKP-P in flexible wall 8.4. INSTALLATION TECHNOLOGY – MKW HONEYCOMB MESH COVER AND KST GRILLE Before installing honeycomb mesh cover, it is necessary to stick 5x10 self-adhesive ceramic gasket, on inside surface of mesh cover, along the deflection, around the perimeter.
  • Page 22 Technical documentation WKP-P Figure 13. Installation method of MKW-D honeycomb mesh cover Figure 14. Installation method of KST grille Page 21 z 31 Version: 6.2 Date of editing: 29.03.2024 r.

  • Page 23: Commissioning

    Commissioning Protocol - Smoke control dampers'. This protocol should be signed by a person holding a current, personalized certificate or certificate issued by Smay Sp. z o. o. authorizing the installation of WKP-P dampers. A copy of this document should be sent electronically to the manufacturer (www.smay.pl  SERVICE AND WARRANTY tab ...
  • Page 24 Technical documentation WKP-P INSTALLATION AND COMMISSIONING PROTOCOL - SMOKE CONTROL DAMPERS Data of the company performing the installation and Device manufacturer commissioning (seal) OBJECT / INSTALLATION LOCATION INSTALLATION AND COMMISSIONING EXECUTION Object Name: …………………………………..…………..…..... KTM-O KTS-O KWP-O ……………………………………………………….…..…….………………………………… KWP-P KWP-Ex KWP-L ……………………………………………………….…..…….…………………………………...
  • Page 25 Control Result: Positive / Negative Recommendations: None / as per the remarks above Client Confirmation: Review Contractor Authorization Signature Number (issued by Smay company) Page 24 z 31 Version: 6.2 Date of editing: 29.03.2024 r.

  • Page 26: Periodic Maintenance And Servicing Rules

    SMAY Manufacturer's Service or an Authorized SMAY Service/SMAY Service Partner. Damage to the WKP-P damper resulting from failure to comply with the guidelines contained in the documentation will not be covered by warranty repairs.
  • Page 27 Technical documentation WKP-P ANNUAL INSPECTION PROTOCOL - SMOKE CONTROL DAMPERS Company performing the inspection (seal) Device manufacturer OBJECT / INSTALLATION LOCATION INSPECTION EXECUTION Date …………………………………………… Nazwa obiektu: …………………………………..…………..…... of execution: … ……………………………………………………….…..…….…… KTM-O KTS-O KWP-O Subject ……………………………………………………….…..…….…… KWP-P KWP-Ex KWP-L of review / Adres obiektu: …………………………...……………..…………...
  • Page 28 None / as per remarks above The next inspection should be performed before ………………………..………..………….. 20…………. r. (Month) Confirmation by the Client: Inspection contractor License number Signature (issued by Smay company) Page 27 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 29 Technical documentation WKP-P Page 28 z 31 Version: 6.2 Date of editing: 29.03.2024 r.
  • Page 30 Technical documentation WKP-P Page 29 z 31 Version: 6.2 Date of editing: 29.03.2024 r.

  • Page 31: Classification Of Dampers For Repair

    The manufacturer provides a warranty for the delivered products, on the terms set forth in the Agreement or the General Warranty Conditions of Smay, Sp. z o.o. The warranty does not cover defects resulting from improper storage, transportation, installation, and commissioning, operation, periodic maintenance, service, especially mechanical damage and damage to anti-corrosive coatings.
  • Page 32 The templates of forms attached to this Technical Documentation (related to installation, commissioning, inspections) are the intellectual property of Smay sp. z o.o. Copying, duplicating, and using them for purposes other than those specified in this Technical and Operating Documentation is prohibited. To maintain the warranty, it is required to fill them out and deliver them to SMAY sp.
