Step 58
To preclude the possibility of a malfunction
(with possible equipment damage) due to
improper adjustment, perform the following
check:
a. Place the selector handle in the decoupled
position.
b. Return the manual operating handle to its
storage position.
c. Reinsert the motor-circuit fuseholder.
d. Operate the switch operator electrically
to open and to close the disconnect as
described in Step 55c. Verify that the rotation
direction of the travel-limit discs for opening
and closing corresponds with the direction
of rotation of the output shaft and that these
directions agree with the direction displayed
in the cutaway section on the outer ring of
the travel-limit discs.
NOTICE
When the switch operator is operated in the
decoupled position, the travel limit discs do
not stop at the indicator-plate positions for
which they were set in Steps 56 and 57. This
may be disregarded.
WIRING AND ADJUSTING THE SWITCH OPERATOR
39
712-502
