USB devices

The ALIF3000 unit has six USB ports (two on the front panel and four on the rear) to
which peripherals may be connected.
To connect more than six peripherals, one or more USB hubs may be used. The total
current that may be drawn from the USB ports is 1.2A, which should be sufficient for
a keyboard, mouse (no more than 100mA each) and any two other devices (500mA
maximum each). If more power for USB devices is required, use a powered USB hub.
To connect USB devices
1 Connect the lead from the device to any
of the USB sockets on the front and rear
panels of the unit.
To USB
peripherals
