StarTech.com MONSTADQI Quick Start Manual

Monitor Riser with Integrated Qi Charging Pad
Product Diagram (MONSTADQI)
1
2
Component
• 23.6 x 9.8 inches (600 x 250 mm) surface area
Stand Top with
• Holds a Monitor, a Mobile Device with
1
Integrated Qi Charger
Wireless Charging Capabilities, and a
Notebook/Paper Documents
• Adjustable height:
2 Legs
• 15W Charging for
3
Qi Charger
Wireless Charging Capabilities
• Connect the Power Adapter (included) to
4 Power Cable
provide power to the Qi Charger
Requirements
For the latest requirements and full manual, please visit:
www.startech.com/MONSTADQI.
• Mobile Device with Wireless Charging Capabilities x 1
• Clean, Flat, and Stable Surface
Installation
Assembling the Monitor Riser
1. Determine the desired height for the Stand Top.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Function
• Legs folded down - 3.3 inches (83.5 mm)
• Legs folded up - 4.5 inches (115.5 mm)
a Mobile Device with
2. (Optional -- Increase the height of the Monitor Riser Legs) Rotate the Height
Adjustment Arms found on the sides of the Legs out and up. The Height
3
Adjustment Arms pivot from a single point in the Legs. Ensure all four Height
Adjustment Arms have been fully rotated out and up before proceeding to the next
step. (Figure 1)
4
3. Place the Stand Top, top side down, onto a Clean, Flat, and Stable Surface.
4. Align the two Pegs on one of the Legs with the two Holes in the Stand Top.
(Figure 2)
5. Firmly press the two Pegs on one of the Legs into the two Holes in the Stand Top.
6. Repeat steps 4-5 to install the second Leg.
7. Flip the Monitor Riser Assembly upright and position it on a Clean, Flat, and
Stable Surface for use.
8. Connect the Power Adapter to the Power Cable and to an available Power Source.
Quick-Start Guide
Figure 1
Pegs
Figure 2
Manual Revision: July 10, 2020
