INFOSEC UPS SYSTEM E4 Evolution II TT Series User Manual page 96

(12) UPS status: The meanings of each icon are listed as below.
3-2-3. Control Screen
Touch icon to enter into the submenu as shown below.
INFOSEC UPS SYSTEM – 15, Rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
95
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 02 19 AA 59 203 07
Icon
Control Menu Tree
UPS status
UPS operates in Standby
mode or Shutdown Mode.
UPS operates in Line mode or
Converter Mode.
UPS operates in Bypass mode
or ECO Mode.
UPS operates in Battery mode
or Battery Test Mode.
UPS operates in Fault mode.
